Food Vacuum Packaging Machine

Food Vacuum Packaging Machine

Share to:
    Payment Type: T/T
    Incoterm: FOB,CIF
    Min. Order: 1 Bag/Bags
    Delivery Time: 10 Days

Basic Info

Model No.: DZR520

Bottom Film Width: 523(mm)

Top Film Width: 493(mm)

Vacuum Supply: 380/50(v/hz)

Machine Dimension: 7585×1100×1700(mm)

Total Power: 13(kw)

Machine Weight: 2300(kg)

Additional Info

Packaging: wooden case

Productivity: 1000

Brand: Vapack

Transportation: Ocean,Land,Air

Place of Origin: China

Certificate: ISO9001:2008

Product Description

product DZR5201 . The frame body 304 food grade stainless steel and food grade aluminum assembly made to ensure the stability of the body and life.
2 . Japan's Mitsubishi touch screen, Mitsubishi computer PLC (3U) make the machine work quality reached the international advanced level.
3 . Germany imported high vacuum environment-friendly type vacuum pump BUSCH202 one, BUSCH40 a vacuum pump.
4 . Mitsubishi precision servo (with brake system) to ensure the accuracy of stepping and running stability.
5 . Taiwan TYC304 stainless steel chains and Germany breaststroke film clip.
6 . Centralized modular pneumatic control valve pneumatic system.
7 . Top film, base film Germany advanced positioning technology and is equipped with inflatable correction means to ensure that the operation of the upper and lower membrane stability and accuracy.
8 . Lifting system adopts link auxiliary lift, studio to ensure no distortion at maximum sealing pressure, does not shift.
9 . The machine is equipped with an emergency safety devices to ensure operator safety.
10 . Heating plate with a whole cast plus custom stainless steel heating pipe, heating system stability reached world advanced level, mold is made of aluminum alloy.
11 . Optical tracking imported from US tri-color sensor (R58ECRGB1).
12 . Recovery system using 2.2KW vortex pump, to ensure that the material under the angle of automatic recovery.
13 . PC tune knife, automatic meter production, make the operation more simple and easier to use.
14 . Host configuration circuit overload protection, effectively improve the safety device

Fifteen. By the French Schneider Electric and Germany polite moving or imported concentrate valve modular valve terminal pneumatic system.

Worth you rely on Vacuum Packaging Machine expert, provide global food security, the main products include: automatic vacuum packaging machine, stretch film vacuum packaging machines, automatic vacuum thermoforming packaging machine, factory vacuum packaging machines, vacuum packaging lines manual Vacuum Packaging Machines, automatic stretch film wrapping machine, a continuous stretch packaging machines, all kinds of custom-made vacuum packaging machine

Xier logo Company plantcompany Honorcompany Honorcompany Honor


Looking for ideal Automatic Food Packaging Machines Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Automatic Multifunction Food Packaging Machine are quality guaranteed. We are China Origin Factory of Electric Food Vacuum Packaging Machine. If you have any question, please feel free to contact us.

Product Categories : Food Series Vacuum Packaging Machine > Other Food Vacuum Packaging Machine
